15V145A 2295W AP306 Power Supply is used to replace failed Zhongtian miner S5 power supplies.
Product parameters:
Model: AP306
Input: 200-240V AC
Output: 15V/145A max IIC
12V/10A
Applications: ZT S5 bitcoin miner 22T
|
nput |
Output |
|||
|
Rated voltage |
200~240Vac |
Voltage |
15Vdc |
12Vdc |
|
Voltage range |
180-280V AC |
Current |
145Amp |
|
|
Frequency |
50Hz/60Hz ± 5% |
Regulation |
±1% |
±3% |
|
Efficiency |
≥93% |
Ripple and noise |
≤200 |
|
|
Withstand voltage |
|
|
Input-output Withstand voltage |
1500V AC |
|
Input-FG Withstand voltage |
1500Vac/10mA/1min |
|
Output-FG Withstand voltage |
500Vac/5mA/1min |
|
perating Environment |
|
|
Operating Temperature |
-40~+55 |
|
Relative Humidity |
0%—85%0%—95% |
|
Storage temp. |
-40~+85 |
|
Cooling |
forced air cooling |
