The SiC654 is a high-frequency integrated power stage optimized for synchronous buck applications to offer high current, high efficiency, and high power density performance with very low shutdown current. SiC654 enables voltage regulator designs to deliver up to 50 A continuous current per phase.

The SiC654 incorporates an advanced MOSFET gate driver IC with high current driving capability, adaptive dead-time control, an integrated bootstrap switch, and user selectable zero current detection to improve light load efficiency.

The SiC654 offer operating temperature monitoring, protection features, and warning flags that improve system monitoring and reliability.

Product features:

1. Highly efficient

- Thermally enhanced PowerPAK® MLP55-31L package

- Vishay’s latest TrenchFET technology and low-side MOSFET with integrated Schottky diode

- Integrated, low impedance, bootstrap switch

- Power MOSFETs optimized for 19 V input stage

- Supports PS4 mode light load requirement with low shutdown supply current (5 V, 3 μA)

- Zero current detection for improved light load efficiency

2. Highly versatile

- 5 V and 3.3 V PWM logic with tri-state and hold-off timer

- 5 V DSBL#, ZCD_EN# logic with PS4 state support

- High-frequency operation up to 2 MHz

3. Robust and reliable

- Delivers in excess of 50 A continuous current, 70 A, peak (10 ms), and 100 A, peak (10 μs)

- Over current protection

- Over temperature flag

- Over-temperature protection

- Under-voltage lockout protection

- High-side MOSFET short detection

4. Effective monitoring and reporting

- Accurate temperature reporting

- Warnings and faults reporting flag

Application:

• Multi-phase VRDs for computing, graphics card, and memory

• Intel core processor power delivery

• Up to 24 V rail input DC/DC VR modules
